| Form1. Tripping Device Mode and Attachment Code | |||||||||
| The over- current tripping |
Alarm Access- ories |
All kinds of accessories | |||||||
| Nothing | The Shunt Tripping Device | The auxiliary contact |
Under Voltage Trip | The auxiliary Contact --The Shunt Tripping Device |
Under Voltage Trip- The auxiliary Contact- The Shunt Tripping Device |
Two Groups Of Auxiliary Contacts | The auxiliary Contact- Under Voltage Trip |
||
| The instantaneous Tripping device |
Nothing | 220 | 210 | 220 | 230 | 240 | 250 | 260 | 270 |
| Alarm Contacts | 208 | 218 | 228 | 238 | 248 | / | 268 | 278 | |
| Complex trip | Nothing | 300 | 310 | 320 | 330 | 340 | 350 | 360 | 370 |
| Alarm Contacts |
308 | 318 | 328 | 338 | 348 | / | 368 | 378 | |
| Frame Degree Rated |
Conventional Thermal Current |
Level Of Short Circuit-Breaking Capacity |
Short Circuit Breaking Capacity | Icu/Ics(KA) | Number Of Poles | Circuit Breaker Of Rated Current |
| AC400V | ||||||
| 63 | 63 | L | 25/18 | Diode Tripolar Quadrupole |
6,10,16,20,25, 32,40,50 ,63 |
|
| M | 50/35 | |||||
| 100 | 100 | L | 35/22 | 10/5 | 10,16,20,25,32 40,50 ,63,80,100 |
|
| M | 50/35 | 20/10 | ||||
| H | 80/50 | |||||
| 225 | 225 | L | 35/25 | 10/5 | 100,125,160,180, 200,225 |
|
| M | 50/35 | 20/10 | ||||
| H | 85/50 | |||||
| 400 | 400 | L | 50/35 | 15/8 | 225,250,315,350, 400 |
|
| M | 65/42 | 20/10 | ||||
| H | 100/65 | |||||
| 630 | 630 | L | 50/35 | 15/8 | 400,500,630 | |
| M | 65/42 | 20/10 | ||||
| H | 100/65 | |||||
| 800 | 800 | L | 50/35 | 15/8 | 630,700,800 | |
| M | 65/42 | 20/10 | ||||
| H | 100/65 |
| I/Ir | Appointed Time | Starting State | |||
| In(A) | |||||
| In≤63 | 63≤In≤225 | In>225 | |||
| Conventional Non-tripping Current |
1.05 | 1h | 2h | Cold | |
| Conventional tripping Current |
1.3 | 1h | 2h | Hot | |
| Return Current | 3.0 | 5s | 8s | 12s | Cold |
| Test Current Name |
Setting Current Multiple |
Appointed Time | Starting State |
| Conventional Non-tripping Current |
Tripolar Energized | <2 | Cold |
| Conventional tripping Current |
Diode Energized | <2 | Hot |
| Frame Degree Rated Current (Inm) | Distribution Protection | Motor Protection |
| 63,100A | 10In | 12In |
| 225,400,630,800A | 5In and 10In | 8In and 12In |
| Model | |||||||
| MS7-125L | MS7-125M | MS7-100L | MS7-100M | MS7-225L | MS7-225M | ||
| Dimensions | C | 85 | 85 | 84 | 84 | 102 | 102 |
| E | 48 | 48 | 50.5 | 50.5 | 50 | 50 | |
| F | 22 | 22 | 22 | 22 | 22 | 22 | |
| H | 72 | 82 | 67 | 87 | 86 | 103 | |
| H1 | 90 | 100 | 84 | 103 | 110 | 127 | |
| H2 | 18 | 28 | 24 | 24 | 24 | 24 | |
| L | 135 | 135 | 155 | 155 | 165 | 165 | |
| L1 | 117 | 117 | 136 | 136 | 144 | 144 | |
| L2 | 117 | 117 | 136 | 136 | 144 | 144 | |
| W | 76(51/2P) | 76(51/2P) | 90(60/2P) | 90(60/2P) | 105 | 105 | |
| W1 | 25 | 25 | 30 | 30 | 35 | 35 | |
| W2 | - | 103 | - | 120 | - | 140 | |
| Installation Size | A | 25 | 25 | 30 | 30 | 35 | 35 |
| B | 117 | 117 | 130.5 | 130.5 | 126 | 126 | |
| Φd | 4.5 | 4.5 | 4.5 | 4.5 | 5.5 | 5.5 | |
| Model | ||||||||
| MS7-400L/3P | MS7-400L/4P | MS7-630L/3P | MS7-630H/3P | MS7-800/3P | MS7-800M/3P | MS7-1250M/3P | ||
| MS7-400M/3P | MS7-400M/4P | MS7-630M/3P | MS7-630R/3P | MS7-800/3P | ||||
| Dimensions | C | 127.5 | 127.5 | 134 | 134.5 | 136 | 136 | 265.5 |
| C1 | 173.5 | 173.5 | 184.5 | 184.5 | 204 | 204 | 345.5 | |
| E | 88.5 | 88.5 | 89 | 89 | 81 | 81 | 97 | |
| F | 65 | 65 | 65.5 | 65 | 66 | 66 | 78 | |
| H | 107 | 107 | 112 | 112 | 116 | 116 | 141 | |
| H1 | 162 | 162 | 164.5 | 164.5 | 168 | 168 | 202 | |
| H2 | 38 | 40 | 41.5 | 42 | 41.5 | 41.5 | 58 | |
| L | 257 | 257 | 270.5 | 270.5 | 280 | 280 | 406 | |
| L2 | 224 | 224 | 234 | 234 | 143 | 243 | - | |
| W | 150 | 182 | 210 | 210 | ||||
| W1 | 48 | 48 | 58 | 58 | 70 | 70 | 70 | |
| W2 | - | 197.5 | - | 240 | - | 280 | - | |
| Installation Size | A | 44 | 44 | 58 | 58 | 70 | 70 | 70 |
| A1 | - | 50 | - | 58 | - | - | - | |
| B | 197 | 194 | 200 | 200 | 243 | 243 | 375 | |
| Φd | 7 | 7 | 7 | 7 | 7 | 7 | 10 | |
Q1:Can I have a sample order?
A1:Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2:What about the lead time?
A2:Sample needed 3-5 days, mass production time needed 1-2 weeks.
Q3:Do you have any MOQ limit?
A3:1pc for sample checking available.
Q4:How do you ship the goods and how long does it take to arrive?
A4:We usually ship by DHL, UPS, Fedex or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping for option.
Q5:Is it OK to print my logo on modified sine wave inverter?
A5:Yes. Please inform us formally before our production and confirm the design firstly based on the sample.
Q6:Do you offer quarantee for the products?
A6:Yes, we offer 18 months warranty.
Q7:Can I get one for sample?
A7:Yes, we accept sample order or trial order for testing first.
Q8:What's the price and MOQ??
A8:NO MOQ. Please just send us inquiry, your inquiry will be replied within 24 hours, we will let you know the latest price.
Q9:What's you delivery time?
A9:It depends on your quantity, usually 1-3 days for sample order, but for batch order, it according to theactual situation.
Q10:How about your payment and shipment?
A10:Payment: We accept T/T, Western Union, Paypal etc. terms of payment.
Shipment: For sample order, we use DHL, TNT, FEDEX, EMS etc.express; for batch order, by sea or by air.
Q11:How about your warranty?
A11:We provide 1.5 and 2 years warranty for different products and whole life technical support.
